Mechanic D75T-B11 0.7-5.0X HD Trinocular Stereo Microscope


Out of stock



Mechanic D75T-B11 0.7-5.0X High Precision HD Trinocular Stereo Microscope for Phone Repair

Magnification: Standard configuration: 7X-50X, optional eyepiece and auxiliary objective can be extended to 3.5X-270X, continuous zoom
Eyepieces: Standard configuration: WF10X22, high eye point wide-angle eyepiece, convenient for observers wearing glasses
Observation head: 45° tilt, 360° rotation, interpupillary distance 54-76MM; bilateral diopter adjustment (±5) diopter
Objective lens: 0.7X–5X continuous zoom, the zoom ratio of the objective lens is 1:7.14, to ensure the parfocality of the image plane
Auxiliary objective lens: 0.5X/0.7X/1X/1.5X/2X optional
Focusing bracket: inner diameter 76mm, column aperture 32mm
Working distance: 100mm
Base: B11 base
Lighting: LED Ring Light
Dimensions: 200*273*240mm
Column height: 240mm

Package includes:
1 x Trinocular microscope
1 x Microscope Base
1 x LED ring light
2 x WF10X/22 eyepiece
1 x CTV 2/5 Adapters

Additional information

Weight6 kg
