Description
ICFriend EMMC UFS Cable Kit Support ICFriend 2-in-1/ 3-in-1 / 4-in-1/ 6-in-1 Modify FPC ISP Cable
Features:
Support ICFriend 2-in-1/ 3-in-1 / 4-in-1/ 6-in-1 Modify FPC ISP Cable
Recommended to use a regulated power supply power supply without USB. press and hold the on button, the current 100~200mA, UFS power up successfully
Using USB power supply and battery device manager need to appear CPU port. If not, UFS power-up is unsuccessful and can not be online
UFS2.0, 2.1, 2.2 use VCC-3.3 V, VCCQ2-1.8V; UFS3.0, 3.1, 4.0 TX RX CLK RST GND all access to the flywire. Like the seat can no longer use USB and power supply, only the host power supply.
GND TX RX signal can not exceed 15mm, GND junction point as close as possible to TX RX to keep equal length, some CPU need RST signal wiring
